TP-Link EAP245 Access Point

Product description

The latest generation of 802.11ac Wawe2 Wi-Fi combined with advanced 3x3 MU MIMO technology ensures superior
Wi-Fi speeds and coverage over 2.4GHz and 5GHz wireless bands.
The EAP245 achieves Wi-Fi speeds of up to 1.75Gbps, with 1300Mbps on the 5GHz band and 450Mbps on the 2.4GHz band.

Easy for Centralized Management

Manage and monitor hundreds of EAPs with ease, all from a single location. The TP-Link Auranet Controller software provides
an intuitive management interface. Control and map out the entire network from any connected PC. There’s no added cost,
and no need for special training. Business Wi-Fi management has never been so efficient and cost-effective.

Efficient Guest Authentication

Captive portal provides one convenient method of authentication for Wi-Fi guests by requiring users to perform certain actions
before network access is allowed. It can Control connections to your network with a voucher system and customized authentication
page that can provide a branded experience, advertise to customers, or offer coupons.

Flexible Deployment

The EAP's low profile design and easy mount chassis make it easy to install on any wall or ceiling surface and allow it to blend in
with most interior decorating styles. EAP devices also support Power over Ethernet (PoE), making deployment effortless and flexible.

Unified Wi-Fi for Multi-user Business Environment

Unified Wi-Fi for Multi-user Business EnvironmentThe Auranet business-grade 11ac Wi-Fi solution is engineered to handle heavy
multi-user usage in large areas without encountering the same stability issues found with standard routers and access points purposed
for home use. It’s the perfect fit for motels, salons, chain-stores, schools, and restaurants.

The Auranet business-grade 11ac Wi-Fi solution is engineered to handle heavy multi-user usage in large areas without encountering
the same stability issues found with standard routers and access points purposed for home use. It’s the perfect fit for
motels, salons, chain-stores, schools, and restaurants.

Key features

• Simultaneous 450Mbps on 2.4GHz and 1300Mbps on 5GHz totals 1750Mbps Wi-Fi speeds
• Supports Seamless Roaming so even video streams and voice calls are unaffected as users move between locations
• Free cloud centralized management and Omada app for ultra convenience and easy management
• Support Power over Ethernet(802.3at/802.3af) for convenient and affordable installation
• Secure guest network along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.
• Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections
• Load balance ensures large numbers of users have smooth network experiences in high density business networks
• Supports management VLAN for an enhanced network management



  Technical parameters

  Wireless features

  Wireless frequency : 2.4 + 5 GHz (dual band)

  WiFi standards : 802.11n, 802.11a, 802.11ac, 802.11b/g

  Transmission speed - 5GHz [Mb/s] : 1300

  Transmission speed - 2.4GHz [Mb/s] : 450

  Tx power 2.4GHz [dBm] : 20

  Tx power 5GHz [dBm] : 23

  Security : 64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK

  2.4GHz MIMO : 3 x 3

  5GHz MIMO : 3 x 3

  Internal antennas : 6

  Roaming : Yes

  Antenna gain [dBi] : 3,5

  Connectors and Interfaces

  LAN speed : (2) 10/100/1000Mbps

  Gigabit LAN : Yes

  Power

  Power over Ethernet : 802.3af, 48V DC

  PoE type : PoE-In (only)

  Max. power consumption [W] : 12,3

  Physical characteristics

  Purpose : Indoor

  Buttons : Reset

  Operating temperature [°C] : 0 up to 40

  Width [mm] : 205

  Height [mm] : 37

  Depth [mm] : 181

  Software

  Operating mode : Access Point

  Management : Omada controller

  Default IP address : Dynamic from DHCP

  Default login and password : admin / admin
