Supermicro SuperServer SYS-2029TP-HTR 2U Twin^2 DP 4x6SFF RED PSU
מק"ט: SYS-2029TP-HTR
- מתלה (2U) 4 מאווררים LGA 3647 (Socket P)
- מספר המעבדים הנתמכים: 2
- מספר חריצי DIMM: 16
- זיכרון פנימי מקסימלי: 2.05 TB
- מספר כונני אחסון נתמכים: 6
- החלפה חמה של מפרצי HDD
- AMI 32 Mbit
- 2200 W
מפרטמידע נוסף

קניה בטוחה



Part number: SYS-2029TP-HTR
Vendor: Supermicro
Num of Nodes: 4-nodes systems
Categories: Multinode Servers
Chassis Form Factor: RACK 2U
Backplanes: SAS3/SATA3
CPU Socket: LGA 3647 (Socket P)
Num of CPU sockets: 2 Per Node
Chipset: Intel C621
Memory Type: DDR4 ECC RDIMM/LRDIMM
Num of DIMM's: 16 Per Node
Num of 2.5 hot-swap bays: 6 Per Node
Storage Controllers: AHCI iSATA 6Gb/s, sSATA 6Gb/s
Power Supply: Redundant
PSU Wattage: 2200 W
Supermicro SuperServer SYS-2029TP-HTR 2U Twin^2 DP 4x6SFF RED PSU
Chassis Form Factor | Rack 2U |
---|---|
Num of systems (nodes) | 4 |
CPU Socket | LGA 3647 (Socket P) |
Num of CPU sockets (per node) | 2 |
Supported CPU's | Intel Xeon Scalable 1st Gen Intel Xeon Scalable 2nd Gen |
Max CPU TDP | 165 W |
Chipset | Intel C621 |
Memory Type | DDR4 ECC LRDIMM DDR4 ECC RDIMM |
Memory Speed | 2933 MHz 2666 MHz 2400 MHz 2133 MHz |
Num of DIMM's (per node) | 16 |
Max Memory Size (per node) | 2048 GB |
Integrated GPU | Aspeed AST2500 |
Num of 2.5 hot-swap bays (per node) | 6 |
Num of PCIe x16 3.0 (per node) | 2 |
Num of USB Ports (per node) | 2x USB 3.0 (rear) |
Num of SATA Ports (per node) | 6 |
Storage Controllers | 6x AHCI iSATA 6Gb/s 4x sSATA 6Gb/s |
Integrated RAID | 0,1,5,10 |
Num of Serial Ports (per node) | 1x Fast UART 16550 (header) |
Network Controllers | SIOM Networking AOC Matrix |
Integrated BMC | IPMI Dedicated RJ45 |
BMC chip | Aspeed AST2500 |
Power Supply | Redundant 1+1 |
PSU Wattage | 2200 W |
PSU Certification | 80+ Titanium |
Chassis Dimensions | 438x 88x 724 mm |
