Ubiquiti UDM-Pro-Max, Dream Machine Pro Max

Product description

UniFi Dream Machine Pro Max is an all-in-one solution (router, firewall and management of all UniFi devices) for
networks in small and medium-sized companies with the possibility of redundancy powered by USP-RPS.
It stands out for its very high performance, which doubles the previous models UDM-PRO and UDM-SE!.
Thanks to higher computing power and larger RAM, you can manage up to 200 UniFi devices
and serve up to 2000 connected clients.

More powerful than ever

The UDM-Pro-Max offers twice the performance of the UDM-Pro or UDM-SE models thanks to a Quad-core ARM Cortex-A57
processor with a frequency of 2GHz, 8GB RAM, 32GB eMMC for the system and 128GB SSD for recording NVR detections.
Thanks to this HW equipment, it is not a problem to achieve a routing performance
of up to 5 Gbps with the IDS/IPS function turned on.

Key features

• (1) 10G SFP+ (1) 2.5 GbE RJ45 WAN ports
• (1) 10G SFP+, (8) GbE RJ45 LAN ports
• (2) HDD bays for 3.5" HDD
• Built-in 128GB SSD
• 1.3" touch screen
• 5Gbps routing performance with IDS/IPS
• Includes full UniFi application suite for device management

Package contents

• Device
• Power cord
• Rack mounts for 19" cabinet
• Screws
• Rackmount screws and cage nuts
• Rubber pads




  Technical parameters

  Connectors and Interfaces

  WAN Ports : 1

  WAN speed : (1) 10/100/1000/2500Mbps + (1) 10Gbps SFP+

  Number of HDD slots : 1

  Multiple WAN : Yes

  LAN speed : (8) 10/100/1000Mbps + (1) 10Gbps SFP+

  Gigabit LAN : Yes

  Optical interfaces : (2) 1G/10Gbps

  Other features : Bluetooth

  Power

  Power type : Mains power (230V), UniFi SmartPower RPS

  Redundant power supply : Yes

  Max. power consumption [W] : 60

  Power via connector/terminal : 230V AC

  Physical characteristics

  Design : Rackmount

  Fans : (1) 60 x 60 mm

  Chassis design : Metal

  Buttons : Reset

  Operating temperature [°C] : -10 up to 40

  Weight [g] : 5

  Width [mm] : 442

  Height [mm] : 44

  Depth [mm] : 286

  Hardware

  CPU : ARM Cortex-A57

  CPU frequency [MHz] : 2000

  CPU cores : 4

  RAM [MB] : 8192

  Software

  Supported VPN : PPTP, L2TP, IPSec, OpenVPN

  Pre-installed controller : UniFi Network, UniFi Protect, UniFi Talk, UniFi Access

  Management : Web management, UniFi Network

  IPv6 support : Yes
